High-Temperature Resistant Double Stroke Hydraulic Cylinder 25MPa
Place of Origin:China
Brand Name:Guoyue
Certification:CE
Model Number:customized
Minimum Order Quantity:1 piece
Payment Terms:T/T
Supply Ability:2500 Ton/Tons Per Year
Product Details
Highlight:
High-Temperature Resistant Hydraulic Cylinder
,Double Stroke Hydraulic Cylinder 25MPa
,Industrial Hydraulic Cylinder with Warranty
Product Name:
Hydraulic Cylinder
Pressure:
Customized
Weight:
55
Power:
25MPa
Dimension(L*W*H):
437*180*229mm
Rod Diameter:
90mm
Maximum Stroke:
30mm
Outer Tube Diameter:
125mm
Inner Tube Diameter:
100mm
Material:
Stainless Steel
Working Medium:
Hydraulic Oil
Technique:
Forging&Casting
Minimum Oeder Quantity:
1PCS
Certifications:
CE
Piston Seal:
Urethane Seal
Seals:
Chinese
Usage:
Metallurgical Industry Machinery
Ship Cost:
Not Include
Product Description
High-Temperature Resistant Double Stroke Hydraulic Cylinder
Premium hydraulic cylinders designed for engineering and metallurgy applications, featuring exceptional high-temperature resistance and double-stroke operation.
| Attribute | Value |
|---|---|
| Product Name | Hydraulic Cylinder |
| Pressure | 1MPa / 25MPa |
| Weight | 55kg / 195kg |
| Dimensions (L*W*H) | 437*180*229mm / 1020*310*306mm |
| Rod Diameter | 90mm / 100mm |
| Maximum Stroke | 30mm / 180mm |
| Tube Diameters (Outer/Inner) | 125mm/100mm / 127mm/100mm |
| Material | Stainless Steel |
| Structure | Y-Type |
| Usage | Machinery |
| Warranty | 1 Year |
| Brand | Guoyue |
| Origin | Jiangsu, China |
Product Features
- High-temperature resistant design for demanding metallurgical applications
- Double-stroke operation provides extended reach and power
- Premium tube construction following GUOYUE CD250 specifications
- Precision ground holes (H8) with surface roughness Ra under 0.4μm
- Durable 45# steel components (head, base, ears, piston)
- Adjustable slow-down system with fixed or floating bumper options
- Ultrasound-tested welds for maximum strength and longevity
- Premium international seals (, Trelleborg, Merkel, GP)
- Rigorous testing to GB/T15622-2005 and Q/GAKY014-2023 standards
- 1-year warranty against manufacturing defects
Key Advantages
This robust hydraulic cylinder excels in extreme environments, offering reliable performance under high temperatures and heavy loads. Its double-stroke design delivers superior reach and power, while premium materials and construction ensure long service life even in the most demanding industrial applications.
Application Scenarios
Ideal for steel mills, foundries, and heavy industrial settings including:
- Heavy-duty presses and forging equipment
- Steel beam handling and positioning systems
- Molten metal processing machinery
- Rolling mill operations
- Large mold handling systems
- Metal processing plant gate mechanisms
Manufacturer Information
- Company: Guoyue Hydraulic Equipment Manufacturing (Jiangsu) Co., Ltd.
- Established: 2022
- Location: Jiangsu, China
- Employees: 51-100
- Markets: Global distribution including North America, Europe, Asia, Africa
- Product Range: Hydraulic cylinders, single/double-acting cylinders, construction machinery cylinders
Quality Assurance
- Pre-production samples for approval
- Final inspection before shipment
- Comprehensive testing protocols
Service & Support
- Accepted Delivery Terms: FOB
- Payment Methods: T/T (USD, EUR)
- Languages: English, Chinese
