Product Details
Highlight:
heavy-duty hydraulic cylinder for metallurgical systems
,customized hydraulic cylinder for steel industry
,iron metallurgical hydraulic system cylinder
Application:
Hydraulic Cylinder For Hydraulic Engineering
Iso:
ISO9001
Mounting Position:
Optional
Valve:
Available In Various Combinations.
Cushioning:
Adjustable
Pressure:
Customized
Working Medium:
Hydraulic Oil
Technique:
Forging&Casting
Minimum Oeder Quantity:
1PCS
Certifications:
CE
Piston Seal:
Urethane Seal
Seals:
Chinese
Usage:
Hydraulic Cylinder For Hydraulic Engineering
Ship Cost:
Not Include
Product Description
Customized Heavy-duty Hydraulic Cylinders for Iron and Steel Metallurgical Hydraulic Systems
Application Field
These heavy-duty hydraulic cylinders are engineered for demanding applications across multiple industries including mining, coalfield operations, oil and gas field development, and metallurgy. They are compatible with crushers, hydraulic supports, tunneling machines, shield tunneling machines, coal mining equipment, and smelting systems.
Product Features
- Compatible with various hydraulic media types
- Designed for high-speed, high-pressure, high-temperature, and overload conditions
- Piston rod can be nickel or chromium plated for enhanced corrosion resistance
- Buffer seal in piston rod dynamic seal extends sealing life
- Dual chamber buffering structures reduce impact and improve operational lifespan
- Multiple end connection options: bolt type, key type, and threaded type
- Customizable integrated valves, sensors, oil port forms, and connection configurations
Technical Specifications
| Cylinder Diameter | Φ40~Φ300mm |
| Rod Diameter | Φ16~Φ280mm |
| Stroke | Up to 15,000mm |
| Working Pressure | Continuous High Pressure up to 400 bar in piston sealing system |
| Instant Pressure | 700bar |
| Piston Rod Moving Speed | ≤4m/s |
| Working Temperature | -41℃~110℃ |
| Cushioning | Adjustable |
| Valve | Available in various combinations |
| ISO Certification | ISO9001 |
| Mounting Position | Optional |
| Primary Application | Metallurgical industry/industrial machinery |
Industrial Applications
- Automated warehouse systems
- Wind turbine blade assembly
- Renewable energy installations
- Deep-sea mining operations
- Aerospace landing gear mechanisms
Customization Options
| Brand Name | Guoyue |
| Origin | China |
| Certification | CE |
| Minimum Order | 1 unit |
| Price Range | $250-$500 |
| Packaging | Wooden Package |
| Delivery Time | 31 days |
| Payment Terms | T/T, L/C |
Support and Services
Our comprehensive technical support includes troubleshooting guidance, maintenance advice, and direct access to specialized engineers. We provide installation assistance, calibration services, and training resources to ensure optimal performance and safe operation.
Packaging and Shipping
Each hydraulic cylinder is carefully packaged in protective materials with clear handling instructions. Units are securely packed in wooden packaging to prevent damage during transportation.
Frequently Asked Questions
What is the brand name of this Hydraulic Cylinder?
The brand name of this Hydraulic Cylinder is Guoyue.
Where is this Hydraulic Cylinder manufactured?
This Hydraulic Cylinder is manufactured in China.
What type of certification does this Hydraulic Cylinder have?
This Hydraulic Cylinder is certified with CE.
What is the minimum order quantity for this Hydraulic Cylinder?
The minimum order quantity for this Hydraulic Cylinder is 1.
What is the price range for this Hydraulic Cylinder?
The price range for this Hydraulic Cylinder is between $250 and $500.
How is this Hydraulic Cylinder packaged for shipping?
This Hydraulic Cylinder is packaged in a wooden package.
What is the delivery time for this Hydraulic Cylinder?
The delivery time for this Hydraulic Cylinder is 31 days.
What are the payment terms accepted for this Hydraulic Cylinder?
The accepted payment terms for this Hydraulic Cylinder are T/T and L/C.
