Created with Pixso. Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action
Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action
  • name
  • name
  • name
  • name

Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action

Brand Name: Guoyue
Model Number: customized
MOQ: 1 piece
Price: USD1,000-10000/pieces
Delivery Time: 12~60 days depends on products type
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
Jiangsu, China
Certification:
iso
Product Name:
Hydraulic Cylinder
Pressure:
1MPa
Weight:
900
Power:
25MPa
Dimension(L*W*H):
1500*100*100mm
Rod Diameter:
150mm
Maximum Stroke:
300mm
Outer Tube Diameter:
200mm
Inner Tube Diameter:
150mm
Material:
Customized
Packaging Details:
Standard Export Package
Supply Ability:
2500 Ton/Tons Per Year
Highlight:

Custom hydraulic cylinder 25MPa

,

Dual action hydraulic cylinder 300mm

,

Hydraulic cylinder with warranty

Product Description
Customized High-quality Dual Action Hydraulic Cylinder 220 140-60 Push Oil Cylinder
Product Specifications
Attribute Value
Product name Hydraulic Cylinder
Pressure 1MPa
Weight 900
Power 25MPa
Dimension (L*W*H) 1500*100*100mm
Rod Diameter 150mm
Maximum Stroke 300mm
Outer Tube Diameter 200mm
Inner Tube Diameter 150mm
Material Customized
Product Description
Our high-quality dual action hydraulic cylinder is engineered for superior performance and durability. The 220mm bore provides exceptional power while maintaining precision operation.
Key Features
  • Tube follows GUOYUE CD250 style with material options: 45#, 42CrMo, or 27SiMn
  • Precision ground holes to H8 with surface finish Ra under 0.4 μm
  • Constructed with 45# steel components (head, base, ears, piston)
  • No cast iron or cast steel used in construction
  • Optional fixed or floating bumpers for controlled deceleration
  • Ultrasound-tested welds for maximum strength and longevity
  • Premium international seals (NOK, Trelleborg, Merkel, GP)
  • Rigorous testing to GB/T15622-2005 and Q/GAKY014-2023 standards
  • 1-year warranty against manufacturing defects
Performance Advantages
This hydraulic cylinder combines raw power with precision control. The 220mm bore delivers exceptional force while the 140mm rod maintains perfect alignment. Dual-action operation ensures consistent performance in both directions. OEM-fit dimensions allow for easy integration into existing systems. Premium seals withstand 60 bar peaks to prevent leaks and ensure reliable operation.
Applications
Ideal for various industrial applications including:
  • Engineering machinery
  • Mining operations
  • Shipping and marine applications
  • Metallurgy processes
  • Water conservancy projects
  • Offshore installations
  • Agricultural equipment
Additional Specifications
Seal Options: Parker, Merkel, NOK, Hallite
Paint Colors: Red, Grey, Yellow, Black (customizable)
Material Options: St52, CK45, 4140, Duplex2205, Stainless Steel 304/316
Certifications: ABS, Lloyds, SGS
Packaging: Bubble-wrap with wooden case
Core Components: Bearing, Pressure vessel, Pump
Structure Types: Piston Type, Plunger Type, Telescopic Type
Power Source: Hydraulic & Pneumatic
Brand: Guoyue
Samples: Available
Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action 0 Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action 1 Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action 2 Custom Hydraulic Cylinder 25MPa 300mm Stroke Dual Action 3
Company Information
Based in Jiangsu, China, we have been serving global markets since 2022 with a team of 51-100 professionals. Our distribution covers domestic and international markets including North America, South America, Europe, Africa, and Asia.
Quality Assurance
  • Pre-production samples provided before mass production
  • Final inspection conducted before shipment
Product Range
We specialize in hydraulic cylinders including single-acting, double-acting, and construction machinery hydraulic cylinders.
Why Choose Us
Guoyue Hydraulic Equipment Manufacturing (Jiangsu) Co., Ltd. is a technology-driven enterprise with 50 million yuan registered capital, specializing in research, design, development, production, and service of hydraulic solutions.
Services
Delivery Terms: FOB
Payment Options: T/T (USD, EUR)
Languages: English, Chinese
