5 Ton Dump Truck 4-Stage Hydraulic Cylinder 16MPa 1500mm Stroke

Name: 5 Ton Dump Truck 4-Stage Hydraulic Cylinder 16MPa 1500mm Stroke
Brand: Guoyue Hydraulic Equipment Manufacturing (jiangsu) Co., Ltd
SKU: customized
Price: 5,000.00 USD
Availability: InStock

Place of Origin:China

Brand Name:Guoyue

Certification:CE

Model Number:customized

Minimum Order Quantity:1 piece

Price:USD1,000-10000/pieces

Payment Terms:T/T

Supply Ability:2500 Ton/Tons Per Year

Product Details

Highlight:

5 ton dump truck hydraulic cylinder

,

4-stage hydraulic cylinder 16MPa

,

hydraulic cylinder 1500mm stroke

Product Name: Hydraulic Cylinder

Power: 16MPa

Dimension(L*W*H): 1775*195*195mm

Rod Diameter: 56mm

Maximum Stroke: 1500mm

Outer Tube Diameter: 102mm

Inner Tube Diameter: 80mm

Overall Length: Customized

Material: Steel, Customized

Surface Treatment Of Piston Rod: Hard Chrome Plated

Pressure: Customized

Working Medium: Hydraulic Oil

Technique: Forging&Casting

Minimum Oeder Quantity: 1PCS

Certifications: CE

Piston Seal: Urethane Seal

Seals: Chinese

Usage: Metallurgical Industry Machinery

Ship Cost: Not Include

Product Description

OEM Hydraulic Cylinder for 5 Tons Dump Truck - 4 Stage Telescopic Design

Product Specifications

Attribute	Value
Product Name	Hydraulic Cylinder
Power	16MPa
Dimension (L×W×H)	1775×195×195mm
Rod Diameter	56mm
Maximum Stroke	1500mm
Outer Tube Diameter	102mm
Inner Tube Diameter	80mm
Overall Length	Customized
Material	Steel, Customized
Surface Treatment	Hard Chrome Plated

Premium Quality Construction

Internals: Cylinder barrel meets GUOYUE EU/US metallurgical standard CD250 structure with 45#, 42CrMo, or 27SiMn materials. Bore honed to H8 precision (Ra<0.4μm). All critical components made of 45# steel.
Buffering: Multiple buffering options including fixed and floating buffer structures for effective deceleration.
Welding: 100% ultrasonic impact treatment on all pressure-bearing welds (≥90% stress removal) for enhanced fatigue strength.
Sealing: Premium imported seals from NOK (Japan), Trelleborg (Sweden), Merkel (Germany), and GP.
Testing: Complies with GB/T15622-2005 and Q/GAKY014-2023 standards. Includes test reports and certificates.
Warranty: 1-year warranty covering defects from design or manufacturing.

Key Advantages

This 4-stage telescopic hydraulic cylinder delivers maximum extension with minimal space requirements. Engineered for high load capacity (5-ton rating), smooth operation, and durable construction with leak-proof seals. Precision manufacturing ensures reliability and long service life in demanding transportation applications.

Applications

Ideal for dump trucks, tipping trailers, refuse vehicles, hydraulic elevators, agricultural equipment, and construction machinery. Particularly suited for waste management, mining, and logistics operations requiring compact yet powerful lifting solutions.

Additional Specifications

Seals: Parker, Merkel, NOK, Hallite
Paint Colors: Red, Grey, Yellow, Black (customizable)
Materials Available: St52, CK45, 4140, Duplex2205, Stainless Steel 304/316
Certifications: ABS, Lloyds, SGS
Packaging: Bubble-wrap with wooden case protection
Structure Types: Piston, Plunger, Telescopic
Power Source: Hydraulic & Pneumatic
Brand: Guoyue
Samples: Available

Product Visuals

Manufacturer Information

Location: Jiangsu, China (Est. 2022)

Markets Served: Domestic (40%), Africa (10%), North America (10%), South America (8%), Southeast Asia (6%), Western Europe (5%), and other global markets

Quality Assurance: Pre-production samples and final inspection before shipment

Product Range: Hydraulic cylinders including single-acting, double-acting, and construction machinery models

Company Profile: Guoyue Hydraulic Equipment Manufacturing (Jiangsu) Co., Ltd. is a technology enterprise with 50 million yuan registered capital, specializing in R&D, production, and service of hydraulic solutions.

Services: FOB delivery terms, USD/EUR payments accepted via T/T, English/Chinese support
