Custom Double Acting Hydraulic Cylinder with Sensor 25MPa

Name: Custom Double Acting Hydraulic Cylinder with Sensor 25MPa
Brand: Guoyue Hydraulic Equipment Manufacturing (jiangsu) Co., Ltd
SKU: customized
Price: 5,000.00 USD
Availability: InStock

Brand Name:	Guoyue
Model Number:	customized
MOQ:	1 piece
Price:	USD1,000-10000/pieces
Delivery Time:	12~60 days depends on products type
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Hydraulic Cylinder

Structure:

Weight:

390

Power:

25MPa

Dimension(L*W*H):

550*127*127mm

Rod Diameter:

56mm

Maximum Stroke:

180mm

Outer Tube Diameter:

127mm

Inner Tube Diameter:

100mm

Material:

Customized

Pressure:

Customized

Working Medium:

Hydraulic Oil

Technique:

Forging&Casting

Minimum Oeder Quantity:

1PCS

Certifications:

Piston Seal:

Urethane Seal

Seals:

Chinese

Usage:

Metallurgical Industry Machinery

Ship Cost:

Not Include

Packaging Details:

Standard Export Package

Supply Ability:

2500 Ton/Tons Per Year

Highlight:

double acting hydraulic cylinder

hydraulic cylinder with sensor

25MPa hydraulic cylinder

Product Description

Custom Double Acting Hydraulic Cylinder with Sensor

Product Specifications

Attribute	Value
Product name	Hydraulic Cylinder
Structure	Y
Weight	390
Power	25MPa
Dimension (L×W×H)	550×127×127mm
Rod Diameter	56mm
Maximum Stroke	180mm
Outer Tube Diameter	127mm
Inner Tube Diameter	100mm
Material	Customized

Premium Quality Hydraulic Cylinders - Quality Assured

Internals: Cylinder barrel adopts GUOYUE EU/US metallurgical standard CD250 structure. Barrel material: 45#, 42CrMo, or 27SiMn. Bore honed to H8 precision with surface roughness Ra<0.4μm.
Buffering: Multiple buffering options including fixed and floating buffer structures for effective deceleration across various pressures and speed ranges.
Welding: 100% ultrasonic impact treatment applied to all pressure-bearing welds, eliminating weld stress (removal rate ≥90%) and enhancing fatigue strength.
Sealing: Exclusively uses premium imported seals from Japan NOK, Sweden Trelleborg, Germany Merkel, and GP.
Testing & Certification: Complies with GB/T15622-2005 standards and internal premium standard Q/GAKY014-2023, including factory test reports and product qualification certificates.
Warranty: One-year warranty from shipment date with free repair or replacement for defects.

Key Advantages

This hydraulic cylinder offers precise control, real-time feedback via sensors, and high durability for demanding applications. Its double-acting design ensures efficient bidirectional force, while customization allows tailored sizing/pressure. Ideal for automation, it reduces downtime, enhances safety, and improves energy efficiency.

Applications

Used in automated manufacturing, construction equipment (excavators/cranes), agricultural machinery, and material handling systems. Also applied in robotics, aerospace actuators, and precision press machines. The sensor integration enables smart monitoring in hydraulic systems, ensuring optimal performance in harsh environments like mining, marine, and energy sectors.

Additional Specifications

Application: Engineering machinery, mine, shipping, metallurgy, water conservancy, offshore, agriculture

Seal: Parker, Merkel, NOK, Hallite

Paint: Red, Grey, Yellow, Black

Material: St52, CK45, 4140, Duplex2205, Stainless Steel 304/316

Certificate: ABS, Lloyds, SGS

Package: Bubble-wrap packing, then in wooden case

Core components: Bearing, Pressure vessel, Pump

Structure: Piston Type, Plunger Type, Telescopic Type

Power: Hydraulic & Pneumatic

Brand: Guoyue

Sample: Available
