Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow

 Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow
 Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow

Large Image :  Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow

Product Details:
Place of Origin: Jiangsu,China
Brand Name: JSRUIYA
Certification: ISO 9000:2016
Model Number: Snow plow Hydraulic Cylinder
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Packaging Details: Wooden box, iron box
Delivery Time: 15-45 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30,000 Pieces/Year

Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow

Description
Bore: 40-200mm Rod: 18-200mm
Stroke: 10-15000mm Working Pressure: 2500-8000PSI
Piston Speed: Maximum 1m/s Temperature Range: -40℃ To +300℃
Types: Single Acting、Double Acting、Telescopic 、Tie Rod And Sensor&positioning Hydraulic Cylinder
High Light:

fisher plow lift cylinder

,

john deere snow plow hydraulic cylinder

Western Meyer Fisher Replacement Snow plow hydraulic cylinders



JSRUIYA Hydraulic Machinery high quality welded single acting snow plow hydraulic cylinders are manufactured in accordance with the needs and standards of the U.S. market. Rigid welded construction, high tensile welded steel end mounts, threaded gland and quality seals allow JSRUIYA Hydraulics’ cylinders to work in harsh conditions. All cylinders are fully and easily maintainable. Each unit is pressure tested before shipping. Cylinders are manufactured in accordance with ISO9001.



Before Purchase, Pls Contact Me , We Can Discuss The Cylinder Details .



Western Meyer Fisher Replacement Snow plow hydraulic cylinders

 Snow Plow Hydraulic Cylinder for Western Meyer Snow Plow 0



SNOW PLOW CYLINDER

Applications: Snow Plow Cylinder Single Acting.
Tube: High tensile cold drawn tube.
Rod: Chrome plated rod.
Gland: Threaded gland with wear rings for long life.
Piston: High tensile heavy duty steel.
Base end: Welded steel end mount.
Piston seals: Top quality five component compact seals for excellent performance.
Rod seals: U-cup polyurethane rod seal with inner O-ring, POM-C wear rings with wiper.
Warranty: 1 year limited warranty.
Pressure: 2500 PSI.
Color: Black.



The key features include:

1/4 inch cylinder wall.
Most cylinders available this size have a 3/16 inch wall which will balloon or rupture with pressure spikes.
5/8 inch base.
Another weak point on most cylinders is the base which is prone to crack or rupture under the extreme conditions plows are put through. Our base is thicker with stronger welds to eliminate this problem.
Screw in gland.
Some cylinders are manufactured with a snap ring gland retainer that is also known to fail. When this occurs the gland is propelled out of the cylinder shearing the through wall fitting. The screw in gland also makes it easier to service or rebuild the cylinder.
3/8 inch wall rod eye and base cross tube.
Thicker and attached with stronger welds than any other cylinder.
Welded ports.
Our welds are the strongest in the industry.
Various base options.
Our basic cylinder comes without a base end. Tangs or cross tubes are available to attach in various configurations to adapt to different plow designs. Our tangs are cut out of 1 inch steel plate which we can be attached to customer specifications.
Optional Lengths.
The standard cylinder has a 20 inch stroke. 16, 24 inch and custom length strokes are also available.



Hydraulic Cylinder Series Available:

Engineering Oil Cylinder Series;
Metallurgy Oil Cylinder Series;
Turn Over Plow Oil Cylinder Series;
Reaper Oil Cylinder Series;
Excavator Oil Cylinder Series;
Quality Gurantee And Service;
One Year Quality Gurantee;
Complete After-Sale Services;



We Can Offered The Nonstandard Cylinders.If You Need OEM Service,Please Give Us The Specification Or The Drawing Of The Cylinder In Order To Give You The Best Service&Price.(Cylinder Diameter,Pressure,Stroke,Application,Installation Method,Mounting Distance Etc).



JSRUIYA Hydraulic Machinery Promise:

1.100% Quality Assurance, Develop And Manufacture Follow Original Ones;
2. Reasonable Stock And Timely Delivery;
3. Quick Response Within 24 Hours ;
4. Long-Term Strong And Steady Supplying Ability;
5. One-To-One Products Factory.Ensure The Best Quality;
6. The First-Class Logistics & Ensure That Your Goods Arrived Safely;
7. Goods Will Be Packed Safe & Carefully;
8. Excellent After-Sales Service.Track Usage.Positive Feedback Response;
9.Establish Inquiry Library For You, We Are Your Professional Sourcing Consultant.


Mechanical Precision Hydraulic Cylinders

JSRUIYA Hydraulic Machinery Have More Than One Decade Experience In Supplying Custom Hydraulic Cylinders With Provided Drawings Or Samples, Or If You Could Provide Following Specification:

1. Diameter Of Bore & Rod
2. Stroke
3. Mounting Style
4. Mounting Distance
5. Working Pressure
6. Ports
7. Seals
8. Special Modifications



Certainly, You Can Provide Drawing And Product Photos So That We Can Understand Your Meaning More Conveniently, Or You Can Also Send Us Sample And We Produce For You According To Your Sample.



Mounting Way:

1. Front And End Of Earring
2. Head Fixed With Flange
3. End Fixed With Flange
4. Vertical To Axis Foot Type
5. Middle Fixed With Pendulum Shift
6 . End With Single Earring



Package&Delivery

1. Each One Packed In Carton Case, Then Put Several Carton Case In The Wooden Case, Supported By The Tray.
2. Depends On The Customers' Requirements.
3. Shipped In 30 Days After 30% Deposit , The Rest Should Be Paid Before Delivery.



Welded Single Acting Hydraulic Cylinders for lifting equipment



Warranty And After-Sale Services:

1.We Provide The Replacement Parts For Free Due To Quality Problems Under Proper Operation Within Warranty Period.
2.After Warranty Period, We Will Charge The Replacement Parts At Cost Price.
3.Consultant Services For Whole Machine Life, And 24 Hours Technical Support By Email;



Payment:

T/T By Our Bank Account Directly, Or By Alibaba’s Trade Assurance Service, Or By The West Union, Or In Cash.



Application:



• Truck And Trailer •Automotive Lifts •Mining •Gas And Oil Industries •Forklifts

• Scissor Lifts •Tractors •Farm Implements •Harvesters •Hay Balers

• Ladder Trucks •Dump Trailers •Lift Gates •Wheel Loaders •Excavators

• Bulldozers •Garbage Trucks •Compactors •Hoist Trucks •Cranes

• Snow Equipment •Wood Splitter

Tie Rod Hay Baler Hydraulic Cylinders



FAQ:

1. Are You Manufacturer Or A Trading Company?
We Are The Manufacturer, And Have Been In This Industry For Nearly Ten Years.


2. What's Your Payment Way?
T/T By Our Bank Account Directly, Or By Alibaba’s Trade Assurance Service, Or By The West Union, Or In Cash.


3. How Can You Ensure The Unit’s Quality After We Put The Order?
Before The Delivery, We Will Send You Machine’s Pictures And Videos, Or You Can Come To Us To Have The Quality Checking By Yourself, Or By The Third Party Inspection Organization Contacted By Your Side.


4. We Are Afraid You Won't Deliver Us The Machine After We Pay You The Money.
Please Note Our Above Business License And Certificates. And If You Don't Trust Us, You Can Use Alibaba’s Trade Assurance Service .


5. Why Choose Your Company?
We Have Been Engaged In The Manufacturing Of Various Hydraulic Power Unit Professionally Nearly 10 Years With Hundreds Of Oil Circuits, Which Can Meet The Needs Of Different Requests.
