Custom Double Acting Marine Hydraulic Cylinder with Chrome Plated Rod
Product Details
double acting marine hydraulic cylinder
,chrome plated hydraulic cylinder rod
,custom marine hydraulic cylinder
| Attribute | Value |
|---|---|
| Power | Hydraulic |
| Dimension (L*W*H) | Depends on the model |
| Rod Diameter | Depends on the model |
| Maximum Stroke | Other |
| Outer Tube Diameter | Depends on the model |
| Inner Tube Diameter | 20mm-1500mm |
| Overall Length | Customized |
| Type | Double Acting Cylinder |
| Material | Steel |
| Surface Treatment Of Piston Rod | Hard chrome plated |
- Tube follows GUOYUE CD250 style with steel options: 45#, 42CrMo, or 27SiMn
- Precision ground hole to H8 with smooth finish (Ra under 0.4 μm)
- Constructed with 45# steel components (head, base, ears, piston) - no cast iron or cast steel
- Optional fixed or floating bumpers for controlled deceleration
- Ultrasound-tested heavy-load welds for reduced stress and extended lifespan
- Premium international seals from Trelleborg (Sweden), Merkel and GP (Germany)
- Rigorous testing to GB/T15622-2005 and Q/GAKY014-2023 standards
- 1-year warranty with free repair/replacement for manufacturing defects
Ideal for marine and coastal applications including:
- Marine construction equipment
- Underwater repair systems
- Coastal excavators and cranes
- Harbor maintenance machinery
- Shipboard hydraulic systems
Also suitable for engineering machinery, mining, shipping, metallurgy, water conservancy, offshore, and agricultural applications.
- Seal Options: Parker, Merkel, Hallite
- Paint Colors: Red, Grey, Yellow, Black (customizable)
- Material Options: St52, CK45, 4140, Duplex2205, Stainless Steel 304/316
- Certifications: ABS, Lloyds, SGS
- Packaging: Bubble-wrap with wooden case
- Core Components: Bearing, Pressure vessel, Pump
- Structure Types: Piston Type, Plunger Type, Telescopic Type
- Pre-production samples for approval
- Final inspection before shipment
- Delivery Terms: FOB
- Payment: USD/EUR via T/T
- Languages: English, Chinese
