3000 psi 4 Inch Bore X 36 Inch Stroke Hydraulic Cylinder

3000 psi 4 Inch Bore X 36 Inch Stroke Hydraulic Cylinder

    • 3000 psi 4 Inch Bore  X 36 Inch Stroke Hydraulic Cylinder
    • 3000 psi 4 Inch Bore  X 36 Inch Stroke Hydraulic Cylinder
    • 3000 psi 4 Inch Bore  X 36 Inch Stroke Hydraulic Cylinder
  • 3000 psi 4 Inch Bore  X 36 Inch Stroke Hydraulic Cylinder

    Product Details:

    Place of Origin: Jiangsu China
    Brand Name: JSRUIYA
    Certification: ISO
    Model Number: Stone cutting equipment steering hydraulic cylinder

    Payment & Shipping Terms:

    Minimum Order Quantity: OEM
    Price: Negotiation
    Packaging Details: Wooden box, iron box
    Delivery Time: 15-45days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 30,000 Pieces/Year
    Contact Now
    Detailed Product Description
    Name: Hydraulic Steering Cylinder Keyword: Steering Hydraulic Ram
    Bore: 4 Inch Rod: 30mm Or Customized
    Stroke: 36 Inch Installation Size: 815mm Or Customized
    Working Pressure: 7.5Mpa
    High Light:

    3000 Psi 4 Inch Hydraulic Cylinder

    ,

    36in Stroke Hydraulic Cylinder

    ,

    36 Inch Stroke Hydraulic Cylinder

    3000 psi 4 Inch Bore X 36 Inch Stroke Hydraulic Cylinder





    Welded Hydraulic Cylinder is ideal for applications where port adjustability and overall hydraulic cylinder space is restricted. The adjustable 360° rotating gland allows you to make port alignments as needed. All ports are recessed to maximize an already slender cylinder design. One port is located on the rotating gland and two on the fixed base. Adjustments are made by using a spanner wrench to rotate the gland with port in a clockwise or counterclockwise direction. The JSRUIYA hydraulic cylinder has become the double acting hydraulic cylinder of choice in applications where the same size cylinder can be used in a variety of directions and port positions, thereby eliminating the need to stock assorted welded hydraulic cylinders. Make reliable farm hydraulic cylinders.



    Technical Parameters:


    Product Name Factory Design Customized Hydraulic Cylinder
    Rod Size 18 mm - 2000 mm(0.71inch - 78.74 inch)
    bore Size 40-200mm(1.57 inch - 7.87inch)
    Stroke 10-15000mm(0.39 inch - 590.55inch)
    Tipping Weight 1 Ton - 100 Ton
    Working Pressure 2500psi - 8000psi(3000psi , 5000psi available)
    Material Carbon Steel/Cast Iron /Aluminum/Hard chrome plated Alloy Steel
    Barrel/Tube 1. Material: SAE1020(20#) , SAE1045(45#) ,16Mn(Q345B),27SiMn,etc.
      2. Technology: cold drawn ,hot rolled,forged
      3. Surface Roughness: R0.16-0.32
      4. Choose by different working condition and requirements.
    Piston rod 1. Material: SAE1045(45#),35CrMo,42CrMo4,etc.
      2. Technology: Quenched and tempered
      3. Surface treatment: chrome plated, nickel-chromium plated, nitriding, nitrocarburizing
    Seal kits 1. Hallite, NOK, SKF, Parker, Hercules,Trelleborg,China made,Taiwan made
      2. Choose by different working condition and requirements.
    Hydraulic Cylinder Types Single Acting Hydraulic Cylinder,Double Acting Hydraulic Cylinder,Telescopic Hydraulic Cylinder,Welded Hydraulic Cylinder,Tie-Rod Hydraulic Cylinder,Bolted Hydraulic Cylinder,Re-phasing Systems Hydraulic Cylinder,Double Rod End Hydraulic Cylinder
    Mounting Style Earrings, flange, foot mounting, trunnion, cross tube, etc
    Test Static balance test
    Surface treatment Painting/sand blasting/oiled,Follow customers' requirement.
    Application Excavator boom arm bucket,Construction,Machinery,Agricultural Machine,Lift gate & Snow plow,Trash Compactors,etc





    Hydraulic Cylinder Series Available:





    1 Ton Hydraulic Cylinder

      10 Ton Hydraulic Ram

    100 Ton Hydraulic Cylinder

     12 Ton Hydraulic Cylinder

    15 Ton Hydraulic Cylinder

    150 Ton Hydraulic Cylinder

     2 Ton Hydraulic Cylinder

     20 Ton Hydraulic Cylinder

    22 Ton Hydraulic Cylinder

    25 Ton Hydraulic Ram

    27 Ton Hydraulic Cylinder

    3 Ton Hydraulic Cylinder

    30 Ton Hydraulic Ram

    35 Ton Hydraulic Cylinder

    40 Ton Hydraulic Cylinder

    50 Ton Cylinder

    60 Ton Hollow Ram

    8 Ton Hydraulic Cylinder

    80 Ton Hydraulic Cylinder



    Before Purchase, Pls Contact Me , We Can Discuss The Cylinder Details .



    We Can Offered The Nonstandard Cylinders.If You Need OEM Service,Please Give Us The Specification Or The Drawing Of The Cylinder In Order To Give You The Best Service&Price.(Cylinder Diameter,Pressure,Stroke,Application,Installation Method,Mounting Distance Etc).



    1. Diameter Of Bore & Rod
    2. Stroke
    3. Mounting Style
    4. Mounting Distance
    5. Working Pressure
    6. Ports
    7. Seals
    8. Special Modifications





    Production Process:



    Cutting Horizontal Bandsaw Hydraulic Cylinder





    Application:



    Truck And Trailer Automotive Lifts Mining Gas/Oil Industries
    Forklifts Scissor Lifts Tractors Farm Implements
    Harvesters Hay Balers Ladder Trucks Dump Trailers
    Lift Gates Wheel Loaders Excavators Bulldozers
    Garbage Trucks Compactors Hoist Trucks Cranes
    Snow Equipment Wood Splitter Loaders Excavator





    FAQ:



    1. Are You Manufacturer Or A Trading Company?
    We Are The Manufacturer, And Have Been In This Industry For Nearly Ten Years.


    2. What's Your Payment Way?
    T/T By Our Bank Account Directly, Or By Alibaba’s Trade Assurance Service, Or By The West Union, Or In Cash.


    3. How Can You Ensure The Unit’s Quality After We Put The Order?
    Before The Delivery, We Will Send You Machine’s Pictures And Videos, Or You Can Come To Us To Have The Quality Checking By Yourself, Or By The Third Party Inspection Organization Contacted By Your Side.


    4. We Are Afraid You Won't Deliver Us The Machine After We Pay You The Money.
    Please Note Our Above Business License And Certificates. And If You Don't Trust Us, You Can Use Alibaba’s Trade Assurance Service .


    5. Why Choose Your Company?
    We Have Been Engaged In The Manufacturing Of Various Hydraulic Power Unit Professionally Nearly 10 Years With Hundreds Of Oil Circuits, Which Can Meet The Needs Of Different Requests.
