Komatsu Volvo Hitachi Hydraulic Cylinder Steel Body Material Non Standard
-
High Light
excavator arm cylinder
,boom hydraulic cylinder
-
PowerHydraulic
-
Body MaterialSteel
-
Standard Or NonstandardNonstandard
-
StructurePiston Cylinder,General Cylinder,Series Cylinder,Other
-
Shaft DiameterCustomized
-
ColorBlue,Gray,according To Customer Requirement,Yellow
-
WarrantyOne Year
-
TypeHitachi Excavator Hydraulic Cylinder,Excavator Boom Hydraulic Cylinder
-
ApplicationExcavator Or Bulldozer,Construction,Excavator,Engineering Machinery Equipment
-
Product NameExcavator Parker Double Acting Hydraulic Cylinder Used,Bucket/ Ram/ Boom Mini Excavator Hydraulic Cylinder
-
SizeOEM
-
CertificationISO9001
-
SealsParker,Hallite,Aston Or Domestic Seals
-
Place of OriginJiangsu,China
-
Brand NameJSRUIYA
-
CertificationISO 9000:2016
-
Minimum Order Quantity1PCS
-
PriceNegotiation
-
Packaging DetailsWooden box, iron box
-
Delivery Time15-45 Days
-
Payment TermsL/C, T/T, Western Union
-
Supply Ability30,000 Pieces/Year
Komatsu Volvo Hitachi Hydraulic Cylinder Steel Body Material Non Standard
JSRUIYA Hydraulic Machinery offers a wide and diverse variety of standard and custom hydraulic cylinders. which include the following:Welded Hydraulic Cylinders ,Tie Rod Hydraulic Cylinders, Custom Hydraulic Cylinders.
HYDRAULIC CYLINDERS TECHNICAL DETAILS:
| 1. Cylinders are of Double Acting / Single Acting type and as per customer drawing. |
| 2. We shall be using seals of Parker/Merkel/Equivalent make |
| 3. Cylinders working pressure will be as per customer specification and test pressure will be 1.5 times of working pressure. |
| 4. Piston Rods will be ground, and hard chrome plated, thickness will be of 25 to 30 microns. bore will be honed to surface finish of <0.4 micron Ra. |
| 5. Ports will be protected with metallic plugs/caps. |
| 6. We will test cylinders as per IS standard test procedure. ( BIS 10585-1983 ) |
| 7. Any spare can be provided on chargeable basis. Special type of painting charges will be extra at actual. |
| 8. Material test certificate, Warranty certificate, dimensional inspection reports& also functional test certificates after inspection shall be submitted along With the material. |
| 9. Our standard guarantee/warranty terms are 12 months from the date of dispatch subject to material and manufacturing defects only. Nonmetallic items, Wear and Tear items are not covered under this warranty |
| 10. Outer construction and mounting of the cylinder will be as per customer GA drawing & specifications, internal design will be ours. We will provide G.A. drawing with mounting details within two weeks after receipt of P.O. for customer approval |
| 11. Material specification for main components of the cylinder are as below |
| a. Piston rod & Piston EN8 C45 / IS1570 |
| b. Outer tube High tensile ST52/Equivalent |
| c. End covers, Tie Rods if required C45/IS 1570/Equivalent. |
| 12. We welcome our customer, or their clients/ representative for inspection at our Works. We will send inspection call once cylinders are ready for dispatch Our end along with duly tested & inspected reports and we will follow your instructions for our further action of dispatch of cylinders. |
Installation method:
The most commonly used mounting options are flange, trunnion, clevis, pin-eye, cross-tube, spherical, and tang. Cylinder mounting is chosen based upon the application’s requirements.
Hydraulic Cylinder Series Available:
| Engineering Oil Cylinder Series; |
| Metallurgy Oil Cylinder Series; |
| Turn Over Plow Oil Cylinder Series; |
| Reaper Oil Cylinder Series; |
| Excavator Oil Cylinder Series; |
| Quality Gurantee And Service； |
| One Year Quality Gurantee; |
| Complete After-Sale Services; |
We Can Offered The Nonstandard Cylinders.If You Need OEM Service,Please Give Us The Specification Or The Drawing Of The Cylinder In Order To Give You The Best Service&Price.(Cylinder Diameter,Pressure,Stroke,Application,Installation Method,Mounting Distance Etc).
JSRUIYA Hydraulic Machinery Promise:
| 1.100% Quality Assurance, Develop And Manufacture Follow Original Ones; |
| 2. Reasonable Stock And Timely Delivery; |
| 3. Quick Response Within 24 Hours ; |
| 4. Long-Term Strong And Steady Supplying Ability; |
| 5. One-To-One Products Factory.Ensure The Best Quality; |
| 6. The First-Class Logistics & Ensure That Your Goods Arrived Safely; |
| 7. Goods Will Be Packed Safe & Carefully; |
| 8. Excellent After-Sales Service.Track Usage.Positive Feedback Response; |
| 9.Establish Inquiry Library For You, We Are Your Professional Sourcing Consultant. |
JSRUIYA Hydraulic Machinery Have More Than One Decade Experience In Supplying Custom Hydraulic Cylinders With Provided Drawings Or Samples, Or If You Could Provide Following Specification:
| 1. Diameter Of Bore & Rod |
| 2. Stroke |
| 3. Mounting Style |
| 4. Mounting Distance |
| 5. Working Pressure |
| 6. Ports |
| 7. Seals |
| 8. Special Modifications |
Certainly, You Can Provide Drawing And Product Photos So That We Can Understand Your Meaning More Conveniently, Or You Can Also Send Us Sample And We Produce For You According To Your Sample.
Mounting Way:
| 1. Front And End Of Earring |
| 2. Head Fixed With Flange |
| 3. End Fixed With Flange |
| 4. Vertical To Axis Foot Type |
| 5. Middle Fixed With Pendulum Shift |
| 6 . End With Single Earring |
Our Company:
Production Process:
Quality Control:
| 1. External Inspection: Purchased Item Inspection, Outsourcing Item Inspection |
| 2. Process Inspection: First Inspection, Random Inspection, Handover Inspection |
| 3. Final Quality Inspection: External Dimensions Inspection, 100% Hydraulic Test |
| 4. Type Inspection:Every Piece Of Hydraulic Cylinder Is Tested And Will Send Out Only After They Are Pasted Each Test. |
Package&Delivery
| 1. Each One Packed In Carton Case, Then Put Several Carton Case In The Wooden Case, Supported By The Tray. |
| 2. Depends On The Customers' Requirements. |
| 3. Shipped In 30 Days After 30% Deposit , The Rest Should Be Paid Before Delivery. |
Warranty And After-Sale Services:
| 1. We Provide The Replacement Parts For Free Due To Quality Problems Under Proper Operation Within Warranty Period. |
| 2. After Warranty Period, We Will Charge The Replacement Parts At Cost Price. |
| 3. Consultant Services For Whole Machine Life, And 24 Hours Technical Support By Email; |
Payment:
T/T By Our Bank Account Directly, Or By Alibaba’s Trade Assurance Service, Or By The West Union, Or In Cash.
Application:
• Truck And Trailer •Automotive Lifts •Mining •Gas And Oil Industries •Forklifts
• Scissor Lifts •Tractors •Farm Implements •Harvesters •Hay Balers
• Ladder Trucks •Dump Trailers •Lift Gates •Wheel Loaders •Excavators
• Bulldozers •Garbage Trucks •Compactors •Hoist Trucks •Cranes
• Snow Equipment •Wood Splitter
FAQ:
1. Are You Manufacturer Or A Trading Company?
We Are The Manufacturer, And Have Been In This Industry For Nearly Ten Years.
2. What's Your Payment Way?
T/T By Our Bank Account Directly, Or By Alibaba’s Trade Assurance Service, Or By The West Union, Or In Cash.
3. How Can You Ensure The Unit’s Quality After We Put The Order?
Before The Delivery, We Will Send You Machine’s Pictures And Videos, Or You Can Come To Us To Have The Quality Checking By Yourself, Or By The Third Party Inspection Organization Contacted By Your Side.
4. We Are Afraid You Won't Deliver Us The Machine After We Pay You The Money.
Please Note Our Above Business License And Certificates. And If You Don't Trust Us, You Can Use Alibaba’s Trade Assurance Service .
5. Why Choose Your Company?
We Have Been Engaged In The Manufacturing Of Various Hydraulic Power Unit Professionally Nearly 10 Years With Hundreds Of Oil Circuits, Which Can Meet The Needs Of Different Requests.
Our services cover all industries and reach all parts of the world.
